Quad Link LVDS Interface HSMC Daughter Card

The Quad Link LVDS Interface HSMC Daughter Card supports receive and transmit LVDS links each consisting of 5 data channels and 1 clock for a total of 48 LVDS channels. The standard default configuration of 20 Tx and 4 Tx clocks and 20 Rx and 2 Rx clocks is capable of supporting flat panel display panels up to 1080p at 100/120Hz. On-board 100 ohm LVDS termination resistors can be removed to convert receiver channels into transmitters as required to support 12 or 14-bit color applications.

The LVDS interface signals can be used for: capturing LVDS video data, connecting to a Camera Link interface or for connecting to flat panel displays using LVDS, Mini-LVDS, RSDS, and PPDS low-voltage panel interface signaling. Custom LVDS daughter cards supporting alternative panel interface headers can be designed to meet your custom requirements.

The card can be used to support development of Camera Link Transmitter IP using the Hirose DF13 - MDR26 Male 1-meter Camera Link adapter cable, PN: [811-MDR26-1M. (For more information contact sales or download the User Manual.)

Included Microtronix IP Core

• Video LVDS SerDes Transmitter/Receiver IP Core. (Evaluation License)

Reference Designs

• LVDS Pass-through
